Case 1107DX Compactor Manual
Compactor Model: 1107DX
Publication Number: 47714442
1st edition
English
October 2014
Format: PDF
Case 1107DX Compactor Service Manual – 623 Pages
Manual Table of Content:
- Content
- Introduction
- Engine
- Rear Axle System
- Hydrostatic Drive
- Brakes and Controls
- Hydraulic System
- Frames and Ballasting
- Steering
- Wheels
- Electrical System
- Plateform, Cab, Bodywork and Decals
- Special Tool Index
Manual Extract: Valve drive and gears – Check
1. Disassemble the top engine assembly, refer to Engine and crankcase – Disassemble — Top Engine (10.001).
2. Disassemble the bottom engine assembly, refer to Engine and crankcase – Disassemble — Bottom Engine (10.001).
3. Check the intermediate gear for damage to its teeth 4. Replace the gear along with the bush bearing if it is damaged
5. Inspect intermediate gear bush internal diameter at two places and at right angles in pressed condition 6. If diameter exceeds the recommended limits replace the bush
7. Inspect the gear support journal diameter for wear with micrometer at two planes and at right angles 1
8. Replace gear support if it is damaged 9. Replace the washers
10. Replace the fasteners if it is damaged
