Manual for: AGCO RTA Tractor
Format: PDF
Book Number: 33785881M7 & 3378579M3
English
Issued September 2008
AGCO RT110A, RT120A, RT140A, RT155A, RT180A Tractor Service Manual
AGCO Parts Catalog
Technician Service Book RTA series tractors
Manual TABLE OF CONTENTS
Introduction
Specification
Engine
Gearbox
Rear Axle
Power take off
Front Axle
Hydraulics
Electrical Equipment
Electronics
Cab and equipment
RT110A, RT120A, RT140A, RT155A, RT180A Manual Extract
Partial kinematics
The engine speed is transmitted to the rear PTO clutch located at the front of the centre housing via a shaftline which passes via:
– the Power Shuttle, the 4 Speed Powershift and the GTA1040 transmission gearbox;
– the Powershift, the Power Shuttle and the GTA1540 transmission gearbox.
The intermediate shaft (2) is splined to the layshaft (13) and drives the driving gears (10) (11) and/or (9) depending on the position of the coupler(s). When a gear transmits the movement to the lower shaftline, the other gear(s) is/are passive and turn(s) idle on its/their axis.
