Table of content of the Service Manual (Service Manual)
- Specification
- Maintenance
- System
- Disassembly
- Troubleshooting
- Engine
- Miscellaneous
All repair and maintenance work listed in this manual must be carried out only by qualified personnel, strictly complying with the instructions given, and using, whenever possible, the special tools.
Thoroughly read and understand this Service manual and the Operators Manual before operating any repair or servicing.
For easy references the manual is breakdown in several chapter with an easy to follow instruction for repairing guidance of the different part of the Excavator.
All information contained in this New Holland Manual is updated
| Engine Model | 3TNE82A-YBD |
| Type | Vertical, 4-cycle water-cooled diesel engine |
| No. of cylinders – Bore X Stroke | 3 – 82mm (3.23 in) X 84 mm (3.31 in) |
| Total displacement | 1.33 liter (81.2 cuin) |
| Compression ratio | 18 |
| Rated output | 24 PS (17.7 kW) at 2400 rpm |
| Maximum torque | 8.1 ~ 8.5 kgfm (58.6 ~ 61.5 lbfft) at 1500 rpm |
| Low idling | 1200 25 rpm |
| High idling | 2590 25 rpm |
| Fuel consumption rate | Less than 175 g / PSh |
| Allowable tilting angles | Back and forth, left and right 25 (momentary 30) |
| Rotating direction | Counterclockwise as seen from flywheel side |
| Firing order | 1-3-2-1 |
